Pumping speed :
50HZ:
l/s : 2
l/min : 120
m3/h : 7.2
cfm: 4.3
60HZ:
l/s : 2.4
l/min : 144
m3/h : 8.6
cfm: 5.1
Extreme pressure:
Pa : ≤40
Torr: ≤3.0*10^-1;
mbar : ≤4.0*10^-1
psi : ≤5.6*10^-3
Noise value dB(A) : ≤57
Leakage rate( vent and gas ballast valve): 1×10^-2Pa·l/s（1×10^-4mbar·l/s）
Maximum inlet/exhaust pressure (MPa ): 0.1/0.13
Working environment temperature (℃/F ): 5～40/41～104
Max water treatment capacity (G/h): 50
Three-phase motor:
Output power (KW/hp): 0.25/0.30
Working voltage (VAC ): 380/220
Speed:
50Hz (rpm): 1410
60Hz (rpm): 1680
Single-phase motor:
Output power (KW/hp): 0.25/0.30
Working voltage (VAC): 220/110
Speed:
50Hz (rpm): 1410
60Hz (rpm): 1680
Inlet/outlet size (mm): KF25/16
Overall dimensions (mm): 430×250×280
Net weight (kg): 18
Gross weight (kg): 27
Cooling way : Air cooling
Other : With gas ballast value
