Pumping:
50HZ: 750 m³/h; 213 L/s
60HZ: - m³/h; - L/s
Ultimate Pressure (mbar ): -
Ultimate full pressure (Gas ballast valve closed) (mbar): 0.1
Ultimate full pressure (Single ballast valve closed) (mbar): 0.3
Ultimate full pressure (Double ballast valve closed) (mbar): 1.5
Motor power (kW): 18.5 kW (50Hz); - kW (60Hz)
Motor speed (rpm): 1450 rpm (50Hz); - rpm (60Hz)
Noise dB(A): 76 db(A) (50Hz); - db(A) (60Hz)
Inlet Size (DN) : DN100
Outlet Size (DN) : DN80
Maximium water vapor extraction (kg/h): 24 kg/h (50Hz); - kg/h (60Hz)
Oil injection quantity (L): 22
Cooling Mode : Water cooled
Weight (kg): 850 kg (50Hz); - kg (60Hz)
Dimensions (mm) (LxWxH): 1600x900x754
