Maxinmum working pressure: 7 / 8 / 10 / 12.5 bar(g) ( equivalent to 102 / 116 / 145 / 181 psig)
Capacity(FAD):
8.36-20.90 m³/min (295-739 cfm)
8.02-20.05 m³/min (283-709 cfm)
6.58-16.44 m³/min (233-581 cfm)
5.91-14.77 m³/min (209-522 cfm)
Installed motor power: 90kW; 120 hp
IP Grade: IP55
Noise level db(A): 80
Dimensions(mm) LxWxH: 2705x1775x1915
Weight (kg): 2625
Air outlet pipe diamete: DN80
Starting Method: Direct Driven; W-Water Cooling
EEI: EEI1
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
Specifications are subject to change without notice.
