Maxinmum working pressure: 7 / 8 / 10 / 12.5 bar(g) ( equivalent to 102 / 116 / 145 / 181 psig
Capacity(FAD):
26.15-74.71 m³/min (923-2638 cfm)
24.68-70.52 m³/min (871-2490 cfm)
22.00-62.85 m³/min (777-2219 cfm)
17.73-50.65 m³/min (626-1788 cfm)
Installed motor power: 400 kW; 550 hp
IP Grade: IP55
Noise level db(A): 80
Dimensions(mm) LxWxH: 4500*2500*2750
Weight (kg): 9240
Air outlet pipe diamete: DN125
Starting Method: Direct Driven; W-Water Cooling
EEI: EEI1
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
Specifications are subject to change without notice.
