Capacity (m³/min): 33
Voltage (V/Hz): 380/50
Compressor power (kW): 5
Circulating cooling water capacity (m³/h): 11.2 (5.9)
Air in/outlet pipe diameter: DN100
Condenser water pipe diameter: ZG1.5
Weight (kg): 560
Dimensions LxWxH (mm): 1840x850x1520
Inlet temperature: ≤ 80°C (recommended ≤ 45°C)
Cooling method: Water-cooling
Inlet pressure: 4 ~ 13 bar
Cooling water inlet temperature: ≤ 32°C
Cooling water inlet pressure: 2 ~ 4 bar
Pressure drop: ≤ 0.3 bar
Dew point: 2 ~ 10°C
Refrigerant: R22
*)m³/min is measured at 1.0 Bar(a), 20℃ ambient temperature and 0% Relative Humidity.
Specifications are subject to change without notice.
