Maxinmum working pressure: 7.5 / 8.5 / 10.5 / 13 bar(g) ( equivalent to109 / 123 / 152 / 189 psig)
Capacity(FAD)*:
50Hz: 24.1 / 24 / 20.51 / 16.61 m³/min ( equivalent to 851 / 847 / 724 / 586 cfm)
60Hz: 24.14 / 24.01 / 18.77 / 15.36 m³/min ( equivalent to 853 / 849 / 663 / 543 cfm)
Installed motor power: 132 kW; 175 hp
driving mode & Cooling method: Direct Driven; Water Cooling
Noise level ** (dBA): 75
Dimensions(mm) LxWxH: 2435x1795x1715
Weight (kg): 2300
Air outlet pipe diamete: DN80
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
***) EEI 2- Energy Effiency Index 2, which refers to normal energy saving series
Specifications are subject to change without notice.
