Power supply AC (V): 380 (3 phase 5 wires)
Automatic phase sequence conversion
Rated maximum gas storage pressure(20℃) (MPa): ≤4
Limit Vacuum Degree (Pa): ≤10
Device vacuum maintaining (Pa): Keep for 24h at 133Pa pressure, the vacuum value raise < 400Pa
SF6 compressor: French Maneurop
Compressor pumping rate: 7m³/h
vacuum pump: 2X-4
Speed Ratio of Suction (m3/h): 54
Adaptive inlet initial pressure of the recovery device(20℃) (MPa): 0~1.0
Electrical equipment recovery final pressure(20℃) (MPa): ≤50 Kpa
Gas oil content control after recovery (μg/g): Domestic oil＜10
Annual leakage rate of the device (%): ＜1
Continuous trouble-free operation time of the device (h): ≥1000
Accumulated trouble-free running time (h): ≥5000
Noise level (dB(A)): complete machine≤75
Theoretical storage capacity (KG): 50
Refrigerated liquefaction compressor: DONPER
Refrigerated storage tank (L): 50
Gas moisture after recovery (PPM/V): 60
Gas oil after recovery (PPM/V): 10
Dry filtration mode: Vacuum heating activation regeneration
At the beginning of air pressure(pa): ≤133
Inflatable end pressure(mpa): 0.8
Inflation rate (m³/h): ≥5
Gasification mode: Electric heating automatic temperature control
Vehicle type: Hand-propelled mobile
Dimension (cm): 1450×810×1200
Total weight (kg): About 600
Cooling mode: Air cooling
Filter system
Using HASON technology in the United States, three-stage filtration -- can remove water, oil, particle impurities and dust in the recovered SF6 gas more efficiently, and ensure the recycled SF6 gas to be reused
Vacuum pump pumping speed (m3/h): 15
Limit Vacuum Degree (Pa): 10
Vacuum pump: Domestic bipolar vacuum pump
SF6 Recovery compressor (m3/h): 7
Pressure (MPa): 2.5
Compressor brand: MANEUROP
Filter particle (micron): 0.02
Oil content (PPM): efficient
Acid value (PPM): 0.1
Hydrolyzable fluoride (PPM): 0.2
Biotoxicity: No
Moisture (PPM): ≤60
SF6 purity: ≥99.9%
SF6 storage tank: 50L
Material of SF6 storage tank: carbon steel
Refrigerating system: High quality and efficient compressor
Filter: America original package
Dryer: America original package
Vacuum gauge: Pointer
Valve: Unique technology (built-in butterfly seal, to ensure that multiple switches will not leak)
