Measure Ranges：
5 to 4000NTU in 5 ranges:
5-50 NTU
5-200 NTU
5-1000 NTU
5-4000 NTU
Automatic: 0 to 4500 mg/L
Calibration:
Range 0-500 mg/L according to NF EN 872
Range >500 mg/L according to NF T 90 105 2
Resolution: 0.01 to 1 NTU/mg/L
Accuracy: <5% of the reading
Temp Unit: NTC
Temp Range: 0.00°C ~+ 50.00°C
Temp Resolution: 0.01℃
Temp Accuracy: ±0.5 °C
Response Time : <5s
StorageTemp: 0°C ~+ 60°C
Dimension Diameter: 27 mm; length: 170 mm
Weight: 300g (sensor+ cable 7 meters)
Electric Wire: 7m
Sensor Cable: Standard: 3.7 and 15 m (other lengthon request).100 m Max. Up to 100 m with junction box.
Signal Interface: Modbus RTU RS-485 and SDI-12
Power Supply:
5 to 12 volts for cable 0-15 m
7 to 12 volts for cable >15 m Max. 13.2 V
Consumption:
- Standby: 40 µA
- Average RS485(1 measure/seconde): 820 µA
- Average SDI12(1 measure/seconde): 4.2 mA
- Current pulse : 500 mA
- Heating time : 100 mS
- Protection against the inversions of polarity
