Measurement Range:
PE: 0.63 - 1219.2mm (0.025 - 48”)
PETP: 0.63 - 1219.2mm (0.025 - 48”)
EE: 2.54 - 152.4mm (0.100 - 6.0“)
EEV: 1.27 - 25.4mm (0.050 - 1.0”)
CT: 0.01 - 2.54mm (0.0005 - 0.100”)
PECT: 0.63 - 1219.2mm (0.025 - 48”)
PECT: 0.01 - 2.54mm (0.001 - 0.100")
Measurement Resolution: 0.01mm (0.001”)
Velocity Calibration Range: 309.88 - 18542m/s (0.0122 - 0.7300in/µs)
Transducer Probe Type: Dual Element
Measurement Accuracy: 0.01mm (0.001”)
Memory: 4GB Internal Memory
Operating Temperature: -10 to 60ºC (14 to 140ºF)
Data Output: USB
Power Supply: 3 x AA batteries and via USB
Battery Life: Alkaline: greyscale 35 hrs, colour 12 hrs, Nicad: greyscale 10 hrs, colour 5 hrs, NI-MH: greyscale 35 hrs, colour 12 hrs
Gauge Weight: 383g (13.5oz) - including batteries
Gauge Dimensions: 63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”)
Packing List: Unit, Selectable Transducer, Couplant, Manual, Plastic Carrying Case, Certificate of Calibration and AA Batteries. PC Software and Data Transfer Cable included with data logging gauges.
