- Temp. Range & Accuracy: －35℃~ +150℃, ±0.1℃
- Temp. Resolution: 0.1℃-Display, 0.1℃-Control
- Temp. Uniformity & Probe: ±0.2℃ at －20℃, PT100
- Pump: Max Flow Rate : 25Lit./min(Controlled 5 Stpes Flow Rate Speed), Max - Pressure: 7.5 psi; Max Lift: 4m
- Bath Volume: 8 Lit.
- Heating Power & Refrigerator: 1 kW; 1/2 HP
- Cooling Capacity: 500W ( +20℃); 340W ( 0℃); 200W (－20℃)
- Refrigerant: CFC -Free(R-404A) Refrigeration System
- Total Power Consumption: 1.7 kW
- Compressor Control: Intelligent Control of Refrigerator for preventing Compressor Overload
- External Circulation Nozzle: id.10.5 / od.12.5 mm (for Inner Circulat: to Connect direclty the in-/outlet Nozzles)
- Timer & Alarm: 99hr 59min (Delay & Continuous run), Error status & Timer-end
- Display: Digital LCD with Back-Light Function
- Controller: Digital Fuzzy Controller with Jog-Dial Knob (Turn+Push)
- Safety Circuit: Over-Temp./-Current protection, Sensor Error Detection, Leakage Breaker
- Material: Stainless-steel (＃304)-Internal, Powder Coated steel-External, 40 mm Thickness Urethane Foaming - Insulation
- Lid & Drain Valve: included Stainless-steel Flat Lid(with Insulation), Ball Valve, Optional Dome Lid,
- Dimension (w×d×h):
EffectiveSpace (mm): 175x153x150
Internal (mm): 175x320x150
External (mm:) 400x523x807
- Gross Weight (kg): 50kg
- Electrical Reqts. AC 230V, 50 / 60Hz
