- Temp. Range & Stability: －20℃ ~ +40℃-Range, ±0.2℃(at 15℃)-Stability
- Cool-Fluid. Filling Volume: 47 Lit max
- Useful for 1~50Lit Evaporators, etc.: for 20~50Lit Evaporator
- Refrigerator Capacity(HP): 2 HP
- Lid & Top Opening Dia:. Φ100 mm
- Fluid In/Out-let Connector: ISO RC 1/2" (English System AG 1/2") Thread, Stainless-steel
- Pump Power, Lift Height, (m):
Max. Flow Rate: 30 Lit/min
Max. Pressure & Lift: 3.3 bar; Max. Lift : 27m
- Cooling Capacity: 6.5 kW( +20℃) ; 3.0kW (0℃); 1.2kW (－20℃)
- External Dimension: 605x975xh1165mm
- Material: Stainless steel-Internal, Powder Coated steel-External
- Electrical Reqts: 3Phase 380V, 60Hz
