Bandwidth (-3dB): DC-30MHz
Rise time: ≤11.6ns
Continuous maximum input range: 70Arms
Max peak current value: 100Apk
Range: 10A (2X); 70A (20X)
Overload: 10A (≥10APk); 70A (≥100APk)
Current transfer ratio: 10A (0.5V/A); 70A (0.05V/A)
Measurable current: 10A (2mA); 70A (20mA)
Amplitude accuracy (DC, 45-66Hz ): 10A (±1%±2mA); 70A (±1%±20mA)
Delay time: Probe (23ns); BNC (1m): 5ns
Terminal load: ≥100kΩ
Power supply: DC 12V/1A（Standard Adaptor）
Voltage of insulated wire: 300V CAT I
Safety compliance
EN61010-1: 2010+A1:2019 EN 61010-2-032:2019
EMC standard: EN61326-1:2013 EN61000-3-2:2014 EN61000-3-3:2013
