Max.Capacity (Tf): 50
Rated output ( mV/V): 2.0 norminal
Zero balance ( mV/V): 0.0±0.2
Combined error (%RO): 0.03
Repeatability (%RO): 0.02
Creep (30 min.) (%RO): 0.03
Temperature effec on
+ Zero value (%RO/10℃ ): 0.03
+ Output value (%RO/10℃ ): 0.03
Excitation
+ Recommend (V ): 10
+ Maximum ( V): 15
Resistance ():
+ Input (Ω ): 760±40
+ Output ( Ω): 700±7
Insulation ( ㏁): ＞2000
Compensated temp.range (℃): -10~+40
Operating temp, ( ℃ ): -20~+80
