Width: 50.8 mm
Height: 34.2 mm
Length: 50.8 mm
Industry: Industrial
Dimensions: 50.8 mm x 50.8 mm x 34.2 mm
Efficiency: 86 %
Output Power: 40 W
Input Voltage: 90 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 8 A
Output Voltage-Channel 1: 5 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
