CUI Inc VGS-200E-5 AC to DC Power Supply 5 Vdc, 40 A, 200 W

Width: 55 mm (2.165 in)

Height: 26 mm (1.024 in)

Length: 194 mm (7.638 in)

Industry: Industrial

Dimensions: 194 mm x 55 mm x 26 mm

Efficiency: 91 %

Output Power: 200 W

Input Voltage: 85 VAC to 305 VAC, 120 VDC to 430 VDC

Mounting Style: Chassis

Input Frequency: 47 Hz to 63 Hz

Load Regulation: Regulated

Isolation Voltage: 4 kV

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 40 A

Output Voltage-Channel 1: 5 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 40 C
