CUI Inc PQQ6W-Q24-D12-S Isolated 12 Vdc, 0.25 A, 6 W, 9-36 Vdc Input Rang

Width: 9.5 mm (0.374 in)

Height: 12 mm (0.472 in)

Length: 22 mm (0.866 in)

Output Power: 6 W

Input Voltage: 9 VDC to 36 VDC

Mounting Style: Through Hole

Isolation Voltage: 1.6 kV

Number of Outputs: 2 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 250 mA

Output Current-Channel 2: 250 mA

Output Voltage-Channel 1: 12 V

Output Voltage-Channel 2: - 12 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
