CUI Inc PEME1-S3-D5-S Isolated 5/-5 Vdc, 0.1/-0.1 A, 1 W, 2.97 - 3.63 V

Width: 6 mm (0.236 in)

Height: 10.16 mm (0.4 in)

Length: 19.65 mm (0.774 in)

Industry: Industrial

Dimensions: 19.65 mm x 6 mm x 10.16 mm

Output Power: 1 W

Input Voltage: 2.97 VDC to 3.63 VDC

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 2 Output

Input Voltage - Max: 3.63 V

Input Voltage - Min: 2.97 V

Input Voltage, Nominal: 3.3 V

Output Current-Channel 1: 100 mA

Output Current-Channel 2: 100 mA

Output Voltage-Channel 1: 5 V

Output Voltage-Channel 2: - 5 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
