Measuring range: -20…50°Ctd
Accuracy:± 1°C at 50…-20 °Ctd; ± 2°C at -20…-50 °Ctd; ± 3°C at -50…-80 °Ctd
Pressure range: -1…50 bar; Special version up to 350 bar
Power supply: 24 VDC (10…36 VDC)
Protection class: IP 65
EMC: In acc. with DIN EN 61326-1
Operating temperature:-20…70 °C
Connection: M12, 5-pin
PC connection: Modbus-RTU interface (RS485)
Analogue output: 4…20 mA (3-wire)
Burden for analogue output: <500 Ω
Screw-in thread: G 1/2″; Optional: UNF 5/8", NPT 1/2"
Dimensions: Ø 30 mm, length approx. 130 mm
Choose units: % RH, °Ctd, g/m³, mg/m³, ppm V/V
Scaling: 4…20 mA change
