Width: 12.7 mm
Height: 5.59 mm
Length: 12.7 mm
Pushing: 0.2 MHz/V
Frequency: 775 MHz to 800 MHz
Power - dBm: 5 dBm
2nd Harmonic: - 15 dBc
Current Rating: 30 mA
Phase Noise Type: - 123 dBc/Hz
Termination Style: SMD/SMT
Tuning Sensitivity: 6 MHz/V
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Tuning Voltage Range - Vt: 300 mVDC to 4.7 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
