Acoustic Specifications
Microphone array: 128 channels MEMS microphone
Effective test bandwidth: 2kHz-48kHz
Dynamic range: 0.5dB-12dB user adjustable
Test sound pressure level range: 25.7-132.5dBA
Auto max/min dB gain: User-settable, minimum test bandwidth 1kHz
Number of digits: 24bit
Sound image FOV: 62°
Sound image frame rate: At least 25 FPS
Leak detection rate: 10m 5bar 0.92ml/s, 0.5m 5bar 0.55ml/s
Detect distances: 0.3m-120m
Camera
Camera FOV: 62°
Camera focal length: 3.04mm fixed focal length
Camera pixel: 8 million pixel
Display
Resolution: 1024*600 (614,400 pixels)
Size: 7 inch
Touch screen: Capacitive touch screen
Brightness: Adjustable
Photo notes: Up to 5 photos notes for reference
Source: Show single or multiple sources
Standard palettes: 3: Grayscale, Ironbow, Blue-Red
Playback function: View photos, videos anytime,and add notes or tags
Storage
Internal storage: About 8G
External storage: TF memory card, at least 64G,expandable to 256G
Data storage format: jpg（Picture）, .mp4（Video）and .wav (Recording)
Video length: 5 minutes
Digital export: TF Card
POWER
Battery capacity: 1×6600mAH@7.2V Rechargeable battery and 1×external battery package, continuous
Battery life: 4+6 hours operation time
Charger: USB Type-C port，USB PD protocol supported, 15W
Power consumption: 15W for battery charge；29W for maximum power consumption
Energy management: Sleep/Auto power off modes
Hardware port
3.5 mm audio jack: Headphone output
USB-C: USB 3.0 Type-C USB host port
Operating Environment
Operating environment: -20℃- +50℃，10%-95% no condensation
Storage temperature :-20℃ – +60℃
Charging temperature: 10℃ – +45℃
General Specifications
Ingress Protection (IP): IP54
Size :272mm×174mm×42mm
Weight :1.7kg
Self-diagnostic notification: Array-health test function to identify when microphone array needs attention
System: Linux system
Certification: CE, FCC, RoHS-compliant, MSDS,CNEX, ATEX
Supported Language
Language: Chinese, English, Korean, French, Japanese, Russian, German, Italian, EU Spanish, Portuguese, Hungarian, Dutch, Cambodian, Vietnamese, Turkish, Polish
Software
Report types: Gas/Electricity,ISO 50001-compliant
Analysis: Waveform, Spectrum,Spectrogram, leakage assessment,discharge type discrimination
