Sensata Technologies - Crydom DRA1-SPF240A25 SSR DIN Mt 280 VAC/8A out 90-140 VAC input

Width: 10 mm

Height: 69.9 mm

Length: 89.6 mm

Output Type: SCR

Unit Weight: 145.500 g

Contact Form: SPST (1 Form A)

Input Current: 10 mA

Mounting Style: DIN Rail Mount

Termination Style: Wire Clamp

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 10 A

Load Voltage Rating: 12 VAC to 280 VAC

Control Voltage Range: 90 VAC to 140 VAC

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
