Sensata Technologies - Crydom 84137860 Indicator 15A/100Vdc DC In FET

Width: 44.5 mm

Height: 30.9 mm

Length: 57.3 mm

IP Rating: IP20

Output Type: MOSFET

Unit Weight: 86.500 g

Contact Form: SPST (1 Form A)

Input Current: 10 mA to 15 mA

Mounting Style: Panel Mount

Termination Style: Screw

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 15 A

Load Voltage Rating: 1 VDC to 100 VDC

Control Voltage Range: 3 VDC to 32 VDC

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C
