Temperature range: -70 to 100 ℃
JTM K07
Temperature fluctuation (100.0℃ or lower): ±0.3 ℃
Temperature fluctuation (100.1℃ or higher): –
Temperature gradient (100.0℃ or lower): 4.0 ℃
Temperature gradient (100.1℃ or higher): –
Spatial temperature deviation (100.0℃ or lower): 3.0 ℃
Spatial temperature deviation (100.1℃ or higher): –
Temperature change rate (Drop): 1.0℃/min. (83 to -53℃)
Temperature change rate (Rise): 3.0℃/min. (-53 to 83℃)
Time to reach temperature extreme (Drop): Within 70 min. (20 to -70℃)
Time to reach temperature extreme (Rise): Within 30 min. (20 to 100℃)
Exterior: Stainless steel plate (SUS430, hairline finish)
Testing chamber volume: 800 L
Testing chamber dimensions (w x d x h): 1000 x 800 x 1000 mm
Product dimensions (w x d x h): 1400 x 1190 x 1795 mm
Refrigerant: Dual refrigeration high-temperature side: R404A, Dual refrigeration low-temperature side: R508A
Controller: Operation modes (set-point or program operation [Steps: 20 per pattern, Repetitions: Max. 98 and infinite])
Safeguards: Earth leakage circuit breaker, operation circuit fuse, electric motor overload safeguard, high-voltage shutdown system, excess temperature increase prevention system, heater overcurrent safeguard, etc.
Equipment: Observation window, cable hole, chamber light, casters, level adjusters, USB port, RS-232C interface, etc.
Accessories: Instruction manual and soft silicon plug for cable hole
Power supply: Three-phase 200V 50/60Hz, Three-phase 220V 60Hz, Three-phase 380V 50Hz
Maximum load current: 44 A
Product weight: 550 kg
