Comet U0122 Datalogger for external CO2 probe up to 10.000 ppm with built-in atmospheric pressure sensor (Li-Ion A8200, 3.6V/5200mAh)

Measured value: Counted values (dew point…), CO2, Atmospheric pressure

CO2 sensor:

Measuring range: 0 to 10 000 ppm

Accuracy: 100 ppm + 5% of the measured value at 23 °C a 1 013 hPa

Resolution: 1 ppm

External probe cable length CO2: 1, 2 or 4 meters

Atmospheric pressure sensor:

Measuring range: 700 to 1100 hPa

Accuracy: ±1.3 hPa at 23 °C from 800 to 1100 hPa

Resolution: 0.1 hPa

Operating temperature: -20 to +60 °C

Channels: internal sensor for atmospheric pressure and CO2 sensor with the cable

Memory: 500 000 values in noncyclic logging mode; 350 000 values in cyclic record mode

Recording interval: adjustable from 10 s to 24 h

Display and alarm refresh: adjustable 1 s, 10 s, 1 min

Recording mode: noncyclic - data logging stops after filling the memory

cyclic - after filling memory oldest data is overwritten by new

Real time clock: year, leap year, month, day, hour, minute, second

Power: Li-Ion battery A8200, 3.6V/5200mAh

Protection class: IP54

Dimensions: 61 x 93 x 53 mm

Weight (including batteries): approx. 260 g

Included in delivery:

U2422

Instruction Manual

Traceable Calibration Certificate

Rechargeable Battery

Power Supply

USB-C Cable

FREE FULL VERSION Analytical Software COMET Vision

CO2 EXTERNAL PROBES ARE NOT INCLUDED IN DELIVERY. THE PROBE WITH A CABLE LENGTH 1, 2 OR 4 METERS MUST BE ORDERED
