Maximum force: 20kN
Measuring units:
- Force: gf, kgf, lbf, N, kN, ozf, tonf (SI), ton (long), tonf (short);
- Pressure: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force resolution: 23 bits
Force accuracy: 1 / 10,000
Measuring stroke: 1200 mm
Stroke resolution: 0.001mm
Distance between two columns: 425 mm (550mm, 680mm, 800mm optional)
Speed range: 25 ~ 650 mm / min adjustable (Digital switch)
PC connection port: TCP / IP (software connection optional)
Speed reaches 1000kg: Above 25mm / min
Speed reaches 2000kg: Over 45mm / min
Sampling rate: 1200Hz max
Hardware safety protection: up / down limit, emergency stop button
Motor type: DC motor
Chassis hardness: 1484 kgf / mm
Power source: single phase 100 / 220VAC, 5A
Dimensions: 86x60x 195 cm
Weight: 190kg
