Width: 18.3 mm
Height: 14 mm
Length: 20.1 mm
Shielding: Shielded
Inductance: 80 uH
Application: NCP1200 Controller
Unit Weight: 6.700 g
Power Rating: 3.5 W
Current Rating: 540 mA
Isolation Voltage: 1.5 kV
Termination Style: Through Hole
Primary Resistance: 4.25 Ohms
Secondary Resistance: 70 mOhms
Maximum DC Resistance: 4.25 Ohms, 70 mOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
