Width: 19.2 mm
Height: 10.5 mm
Length: 22.5 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 8.2 uH
Application: High Current
Termination: Standard
Unit Weight: 13.500 mg
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 18.5 A
Saturation Current: 15.8 A
Maximum DC Resistance: 2.76 mOhms
Self Resonant Frequency: 18 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
