Width: 21.1 mm
Height: 17.3 mm
Length: 21.1 mm
Shielding: Unshielded
Inductance: 400 uH
Application: LT3799 Isolated Led Controller
Unit Weight: 14 g
Power Rating: 24 W
Current Rating: 1 A
Frequency Range: 100 kHz
Isolation Voltage: 3 kV
Termination Style: Through Hole
Maximum DC Current: 1.3 A
Number of Channels: Single
Primary Resistance: 252 mOhms
Secondary Resistance: 126 mOhms
Maximum DC Resistance: 252 mOhms, 126 mOhms, 149 mOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
