Width: 26 mm
Height: 14 mm
Length: 26.75 mm
Shielding: Unshielded
Inductance: 7.5 uH
Application: LT3751 Capacitor Charger Controller
Unit Weight: 25 g
Current Rating: 3.6 A
Frequency Range: 100 kHz
Isolation Voltage: 1.5 kV
Termination Style: SMD/SMT
Maximum DC Current: 5 A
Number of Channels: Single
Primary Resistance: 18 mOhms
Secondary Resistance: 20 mOhms, 31 mOhms, 31 mOhms
Maximum DC Resistance: 31 mOhms, 31 mOhms, 20 mOhms, 18 mOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
