Width: 6.1 mm
Height: 5 mm
Length: 8.89 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 20 %
Inductance: 560 nH
Application: Automotive
Termination: Standard
Unit Weight: 31.500 mg
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 6 A
Saturation Current: 7.7 A
Maximum DC Resistance: 10 mOhms
Self Resonant Frequency: 200 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
