User Interface: In-Sight Explorer EasyBuilder, Cognex VisionView PC Software, and VisionView 900 HMI touchscreen panel
1/3: Monochrome and Color
S-Mount/M12 Lenses: Standard: Autofocus (liquid lens) 6.2 mm or 16 mm
Image Modes: 640 x 480 (standard) / 640 x 480 (2x magnification) / 800 x 600 (2x magnification)
Lighting: Standard: Diffuse: Modular red and white LEDs / Options: White, blue & IR LED lights, band-pass filters, polarizing filter, and polarized light cover
Maximum Acquisition Speed: 75 fps (mono) / 55 fps (color)
Relative Processing Speed: 2x
Data Output: Pass/Fail, Numeric
General Protocols: TCP/IP, UDP, FTP, Telnet, RS-232C
Industrial Protocols: EtherNet/IP with AOP, PROFINET, SLMP, SLMP Scanner, CC-Link IE Field Basic, Modbus TCPEtherNet/IP with AOP, PROFINET, SLMP, SLMP Scanner, CC-Link IE Field Basic, Modbus TCP
Connectors: (1) Industrial M12 Ethernet, (1) M12 Power & I/O
Inputs & Outputs: (1) Acquisition trigger, (1) General purpose input4, (4) General purpose outputs
Dimensions: In-line configuration: 43.1 mm (1.69 in) x 22.4 mm (0.88 in) x 64 mm (2.51 in) / Right-angle configuration: 43.1 mm (1.69 in) x 35.8 mm (1.40 in) x 49.3 mm (1.94 in)
Weight: 142 g (5 oz)
Material and Protection: Painted aluminum, IP65-rated housing
Power: 24 VDC +/- 10%, <3.0 W or Class 1 Power over Ethernet (PoE)
PoE Configuration Available: yes
Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Location Tools Pattern: Yes
Location Tools Edge, Circle: Yes
Inspection Tools Pattern: Yes
Inspection Tools Pixel Count: Grayscale
Inspection Tools Brightness & Contrast: Yes
Inspection Tools Edges: Yes
Measurement & Counting Tools Distance, Angle & Diameter: Yes
Measurement & Counting Tools Patterns & Edges: Yes
Advanced Features OCR: Yes
Advanced Features Blob Detection: Yes
Advanced Features Image Filters: Yes
