Algorithms: 1DMax, 2DMax, Hotbars, PowerGrid
Image Sensor: 1/1.8″ CMOS
Image Sensor Properties: Diagonal 8.9 mm; 3.45 μm square pixels
Resolution: 2048 x 1536
Electronic Shutter Speed: Min. exposure: 15 μs Max. exposure: 1000 μs with internal illumination/10000 μs with external illumination
Max Acquisition: Up to 80 Hz
Lenses: Liquid lens 10 mm, 16 mm, 24 mm; C-mount 12 mm, 16 mm, 25 mm, 35 mm, 40 mm
Trigger and Tune Buttons: Yes; Quick Setup Intelligent Tuning
Aimer: Optional
Discrete Inputs: 2 fixed + (*) opto-isolated
Discrete Outputs: 2 fixed + (*) opto-isolated
Other I/O points: 2 user-configurable
Status Outputs: Beeper, 5 multifunctional LEDs, 10 LED bar array, 360-degree indicator
Lighting: Integrated LEDs, red, blue or IR; diffuse, polarized, high powered integrated light (HPIL), high powered integrated torch (HPIT), various controllable external light options
Connectivity: Ethernet and serial
Protocols: RS-232, TCP/IP, PROFINET, EtherNet/IP, SLMP, Modbus TCP, NTP, SFTP, FTP, MRS, Java Scripting enabled for custom protocols
Power Consumption: 24 VDC ±10%, 1.5 A maximum (HPIL/HPIT) 24 VDC, 250 mA maximum (reader) Supplied by LPS or NEC class 2 only
Weight: 165 g
Dimensions (L x W x H): 73 mm x 54 mm x 42 mm; 113 mm x 91 mm x 75mm (with HPIT)
Operating Temperature: 0 °C–57 °C (32 °F–134.6 °F)
Storage Temperature: -20 °C–80 °C (-4 °F–176 °F)
Humidity: < 95% non-condensing
Standard: IP67 with appropriate cables and lens cover included
