Cincon NCS01W8-48S033 Non-Isolated / PoL 6-72Vin 3.3Vout 1A

Width: 8.6 mm (0.339 in)

Height: 17.5 mm (0.689 in)

Length: 12.1 mm (0.476 in)

Industry: Industrial

Dimensions: 12.1 mm x 8.6 mm x 17.5 mm

Output Type: Fixed

Output Power: 5 W

Input Voltage: 6 VDC to 72 VDC

Mounting Style: Through Hole

Number of Outputs: 1 Output

Input Voltage - Max: 72 V

Input Voltage - Min: 6 V

Input Voltage, Nominal: 48 V

Output Current-Channel 1: 1 A

Output Voltage-Channel 1: 3.3 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
