Width: 57.9 mm (2.28 in)
Height: 25.4 mm (1 in)
Length: 104 mm (4.094 in)
Industry: Medical
Approvals: EN/IEC/UL 60601-1, 62368-1
Dimensions: 104 mm x 57.9 mm x 25.4 mm
Efficiency: 93 %
Output Power: 300 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4.25 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 25 A
Output Voltage-Channel 1: 12 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
