Cincon EC7AW-48S15 Isolated 10W 18-74Vin 15Vout 666mA

Width: 20.3 mm (0.799 in)

Height: 10.2 mm (0.402 in)

Length: 31.8 mm (1.252 in)

Industry: Industrial

Dimensions: 31.8 mm x 20.3 mm x 10.2 mm

Output Power: 10 W

Input Voltage: 18 VDC to 74 VDC

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 74 V

Input Voltage - Min: 18 V

Input Voltage, Nominal: 48 V

Output Current-Channel 1: 666 mA

Output Voltage-Channel 1: 15 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
