Width: 7.2 mm (0.283 in)
Height: 10.2 mm (0.402 in)
Length: 19.6 mm (0.772 in)
Dimensions: 19.6 mm x 7.2 mm x 10.2 mm
Efficiency: 82 %
Unit Weight: 2.700 g
Output Power: 2 W
Input Voltage: 10.8 V to 13.2 V
Cooling Method: Convection
Mounting Style: Through Hole
Mechanical Style: Isolated
Isolation Voltage: 1 kV
Number of Outputs: 2 Output
Input Voltage - Max: 13.2 V
Input Voltage - Min: 10.8 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 83 mA
Output Current-Channel 2: 83 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
