Cincon DH30W10-800S12P Isolated 30W 150-1500Vin 12Vout 2.5A

Width: 63.5 mm (2.5 in)

Height: 24.994 mm (0.984 in)

Length: 3.5 in

Industry: Industrial

Dimensions: 3.5 in x 2.5 in x 0.984 in

Output Power: 30 W

Input Voltage: 150 VDC to 1.5 kVDC

Mounting Style: Through Hole

Isolation Voltage: 4 kV

Number of Outputs: 1 Output

Input Voltage - Max: 1.5 kVDC

Input Voltage - Min: 150 VDC

Input Voltage, Nominal: 800 VDC

Output Current-Channel 1: 2.5 A

Output Voltage-Channel 1: 12 V

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
