Width: 50.8 mm (2 in)
Height: 27 mm (1.063 in)
Length: 101.6 mm (4 in)
Industry: Industrial
Efficiency: 81 %
Unit Weight: 170 g
Output Power: 40 W
Input Voltage: 90 VAC to 264 VAC
Cooling Method: Convection
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Mechanical Style: Open / Enclosed Frame
Isolation Voltage: 4.24 kVDC
Number of Outputs: 2 Output
Input Voltage - Max: 264 VAC
Input Voltage - Min: 90 VAC
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 5 A
Output Current-Channel 2: 1.5 A
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 24 VDC
Operating Temperature Range: 0 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
