Width: 50.8 mm (2 in)
Height: 34.6 mm (1.362 in)
Length: 116.8 mm (4.598 in)
Industry: Industrial
Approvals: IEC/EN60335-1/60601-1
Efficiency: 94 %
Unit Weight: 240 g
Output Power: 150 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 5.35 A
Output Voltage-Channel 1: 28 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 30 C
