CHROMA 63303A DC Electronic Load Module (60A/80V/300W)

Power: 30W/ 300W

Current: 0~6A/ 0~60A

Voltage: 0~80V

Min.OperationVoltage(DC) (Typical):

0.4V@3A/ 0.4V@30A

0.8V@6A/ 0.8V@60A

Constant Current Mode

Range: 0~6A/ 0~60A

Resolution: 1.5mA/ 15mA

Accuracy: 0.1%+0.1%F.S./ 0.1%+0.2%F.S

Constant Resistance Mode

Range:

0.025Ω~100Ω (300W/16V)

1.25Ω~5kΩ (300W/80V)

Resolution: 12 bits

Accuracy:

100Ω: 0.1 Ω + 0.2%

5kΩ: 0.01 Ω + 0.1%

Constant Voltage Mode

Range: 0~80V

Resolution: 20mV

Accuracy: 0.05% ± 0.1%F.S.

Constant Power Mode

Range: 0~30W/ 0~300W

Resolution: 7.5mW/ 75mW

Accuracy: 0.5% ± 0.5%F.S

Dynamic Mode

Dynamic Mode: C.C. Mode

T1 & T2:

0.025ms ~ 50ms / Res: 5µs

0.1ms ~ 500ms / Res: 25µs

10ms ~ 50s / Res: 2.5ms

Accuracy: 1µs/1ms+100ppm

Slew Rate: 0.001~0.25A/µs/ 0.01~2.5A/µs

Resolution: 0.001A/µs/ 0.01A/µs

Min. Rise Time: 10µs (Typical)

Current: 0~6A/ 0~60A

Resolution: 1.5mA/ 15mA

Current Accuracy: 0.4%F.S.
