Measuring/illumination aperture: Φ2mm/5mm，Φ1.5mm/3mm
Battery capacity: Single charge can measure 8000 times continuously, 7.2V/3000mAh
Density range: 0.0 D–3.0 D
Density Standard: Status A, E, I, T, M
Comply with standards: ISO 5-4:2009(E), ISO 13655:2017, CIE No.15
Instrument Display: Full color screen, 3.5 inches
Supported languages: Chinese Simplified，English
Lighting source: Full-band balanced LED light source + UV
Measurement Mode: M0, M1, M2, M3
Measurement structure*: 45/0
Measurement time: About 1.5 seconds
Measurement repeatability**: Density value: ≤0.001D, chromaticity value: dE*ab≤0.03
Wavelength interval: 10nm
Wavelength range: 400-700nm
Light source life: 1 million times in 10 years
Storage Instrument: 100 standard samples, 10,000 test samples; APP: Massive storage
Spectral method: Grating
Sensors: Dual-row high-precision CMOS array sensor
Reflectivity measurement range: 0-200%
Reflectivity resolution: 0.01%
Software Support: Android, iOS, Windows, WeChat Mini Program
Accuracy Guarantee: Ensure first-level measurement qualification
Display accuracy: Density value: 0.001, Chroma value: 0.01
Viewer angleL: 2°，10°
Printing quality indicators: Color density CMYK(A, T, E, M), dotarea, dotareagain, overprint rate, printing contrast, grayscale, hueerror
Inter instrument agreement: dE*ab≤0.3
Measuring indicators: /
Lighting conditions: A, B, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, U30, U35, DLF, NB F, TL83, TL84, ID50, ID65, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-BH1, LED-RGB1, LE D-V1, LED-V2
*45 degree ring lighting/0 degree angle reception
**Measure the standard deviation of the white board 30 times at 5 second intervals
after white board calibration (exceptM3)
***BCRA series II 12 color plates M0 mode 5mm diameter measurement average value (except M3)
