Illumination/ Viewing System: Reflection :d/8(diffuse lighting,8° direction reception), transmission :d/ 0 (diffuse lighting, vertical direction reception);
SCI(including specular reflected light)/SCE(not including specular reflected light) measurement at the same time;
Compliance with: CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724/1,DIN5033 Teil7,JIS Z8722 Conditions C,ASTM E1164,ASTM-D1003-07
Sensor: Dual-row high precision CMOS array sensor
Grating Method: Concave Grating
Sphere Diameter: 152mm
Wavelength Range: 360nm-780nm
Wavelength Pitch: 10nm
Half Band Width: 1.6nm
Reflectance Range Resolution: 0-200%,0.01%
Light Source: Pulse Xenon Lamp and LED
UV Measurement: Include UV, 400nm cut, 420nm cut, 460nm cut
Measurement Time: Single mode＜2s
Measurement/Illumination Aperture
Reflection: XLAV Φ25.4mm/Φ30mm, LAVΦ15mm/Φ18mm, MAVΦ8mm/Φ11mm, SAVΦ3mm/Φ6mm
Users can customize the caliber, automatic identification of caliber switching Transmission: Φ17mm/Φ25mm
Transmittance Sample Size: No limit on sample width and height, thickness ≤50mm
Long Term Repeatability: XLAV Chromaticity value: Standard deviation within ΔE*ab 0.015 (20℃±10℃ arbitrary temperature change, white tile is measured every hour within 24 hours）
Repeatability: XLAV Spectrum Reflectance/Transmittance: standard deviation within 0.1%;XLAV Chromaticity value: Standard deviation within ΔE*ab 0.015 * When a white tile is measured 30 x at 10-second intervals after white calibration
Inter-Instrument Agreement: XLAV ΔE*ab 0.2 (BCRA Series II, Average measurement of 12 tiles, at 23℃)
Observer: 2° and 10°
Illuminants: A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,DLF,NBF,TL83,TL84
Language: English, Russian, Spanish, Portuguese, Japanese, Thai, Korean, German, French, Polish, Chinese (simple and traditional),
Display: Reflectance and Transmittance graph/value, color value, color difference values, pass/fail, color simulation, color assessment, haze, liquid chromaticity values, color tendency
Color Spaces: CIE LAB,CIE LUV,LCh,Hunter Lab,Yxy,XYZ,Musell,s-RGB,βxy
Other Indices:
WI(ASTM E313-00,ASTM E313-73,CIE/ISO, AATCC, Hunter, Taube Berger, Stensby)
YI(ASTM D1925,ASTM E313-00,ASTM E313-73),Tint(ASTM E313-00),Metamerism index milm, stain fastness,color fastness, ISO brightness, R457, A density, T density, E density, M Density, APHA/Pt-Co/Hazen, Gardner, Saybolt, ASTM color, Haze, Total Transmittance, Opacity, Color Strength
Color Difference: ΔE*ab, ΔE*CH, ΔE*uv, ΔE*cmc, ΔE*94, ΔE*00, ΔE*ab(hunter),555 shade sort
Storage Memory: 8GB
Screen Size: 7 Inches Touch Screen
Operate System: Android
Power Adaptor: 12V/3A
Operate Temperature: 5-40℃(40-104F), relative humidity 80% (at 35℃) no condensation
Storage Temperature: -20-45℃(-4-113F), relative humidity 80% (at 35℃) no condensatio
Other Function: RS-232、USB、USB-B
Interface: 1. Camera to view measurement area;2. Support horizontal, vertical and downward measurement method (need optional accessories to support for downward measurement);3. Auto humidity and temperature compensation function.
Accessories: Power Adaptor, USB Cable, fixture for transmittance, U disk (PC software), Black Calibration Cavity, White and Green Calibration Tile, Reflectance Test Support,30mm,18mm,11mm and 6mm apertures,reflectance sample fixture, Glass Cell 40x10mm,reflectance fixture
Optional Accessories: Heating Fixture for Transmittance, Vertical Support and Pneumatic ram for downward measurement, Reflectance fixture for small size sample, Reflectance Glass Cell Support, Corrosion-Resistant Protective Plate (non-removable), Sample Holder for Fiber, Film Fixture, Transmittance Fixture for Small Aperture, Trolley Case, European Standard Plug, American Standard Plug
