Chauvin Arnoux PEL52 Power and Energy Loggers (2 single-phase)

General functions

- Display: Multi-display backlit LCD

- Types of installations: Split-phase or 2 single-phase channels

- Number of channels: 2V/2I

- Network frequency: 50 and 60 Hz

- Voltage: 10 V to 690 V

- Ratios: Yes

- Power/energy values: P, Pf, N, S, Qf, D / Up to 4 Exa

- Min – Max: Yes

- THD: Yes

Additional functions

- Acquisition rate : 1 measurements / s

- Aggregation: 1 min to 60 min

- Storage mode: SD / SD-HC card; 8 GB (expandable to 32 GB)

- Ethernet : Yes (via simplified Wifi)

- Safety: IEC 61010 CAT III 600 V

- Power supply: Via the measurement phase (90 – 690 V)

- Battery: NiMH – Battery life 1 hour

- Dimensions: 180 x 88 x 87 mm

- Weight: 400 g

- Casing: IP54
