Chauvin Arnoux MA400D-250 clamp meter (AC 400A)

Display range: 4 A AC- 40 A AC - 400 A AC

Measurement range: 0.020 A-3.999 A; 4.00 A-39.99 A; 40.0 A-399.9 A

Resolution : 1 mA; 10 mA; 100 mA

Accuracy: ± (2% + 10 cts); ± ( 1.5 %+ 2 cts); ± (1.5 %+ 2 cts)

Sensor clamping diam. / length: Ø 70 mm / 250 mm

Bandwidth: 10 Hz - 3 kHz- Power supply: 2 x 1.5 V AAA/LR3 batteries

Safety: IEC 61010 CAT IV 600V

Operating temperature: 0°C to +50°C

Instrument weight: Approx. 130 g

Casing dimensions: 100 x 60 x 20 mm

Length of connection cable: 0.8 m

State at delivery: 1 DigiFLEX sensor delivered in a blister pack with 2 x 1.5V AAA batteries, 1 elastic strap and an operating manual in 5 languages

Accessories & Replacement Parts: Bag 120 x 200 x 60 P01298074MULTIFIX accessories P01102100ZElastic strap P01102113
