Measuring range: 0-40%vol H2O
Sensor: Ion flow humidity sensor
Accuracy: ±2%FS(Accuracy is only available for communication output,analog signals maybe addi-tional error in signal acquisition)
Repeatability: ±1%FS
Stability: ±1%FS/7d
Response time: Fully preheated,T90 less than 60s
Background gas: N2,He,Ar and other inert gases,and can not contain Si,Pb,etc.
Display: 128×64 OLED screen
Wiring method: terminal
Installation: DN50 standard flange
Sensor life: more than 2 years (normal use)
Analyzer life: more than 5 years (normal use)
Working method: online
Probe insertion depth: 500mm,1000mm,1200mm,1500mm or other sizes
Sampling method: Plug-in measurement
Power: 24VDC
Analyzer power consumption: less than 20VA
Calibration cycle: It is recommended to calibrate every other year
Measured ambient temperature: Probe:100~500°C. Ambient temperature of electrical module: -10~+50°C
Storage environment: Temperature:-20~+60°C. Humidity:less than 90% RH
Sample gas pressure: normal pressure±10% (only during ventilation)
Sample gas flow: 800~1000ml/min (only during ventilation)
Communication: Interface:terminal block Communication method:RS485(standard)/RS232 (optional). Modbus RTU protocol
Analog signal: 1 group,4-20mA/0-20mA/0-1V/0-5V/ 0-10V/1-5V,can set analog output mode. load:less than 500Ω
