Measurement components and ranges: 0-25.0% O2 Can be extended according to user needs
Detection principle: Magneto-mechanical Technology
System power supply: 220 VAC±10% 50/60Hz
System power consumption: Less than 50VA
Alarm: 1-way alarm output
Relay contact capacity: 24VDC, 0.2A
Signal output: A group of 4-20 mA outputs correspond to O2 respectively.
Environmental temperature: 0-45°C; Environmental humidity:Less than 80% RH
Intake pressure: Use of suction pumps at negative and micro-positive pressures
Sample flow rate: 4-6L/min
Inlet and outlet Interfaces: G1/4 Internal Thread Interface
Analyzer life: More than 5 years (normal use)
Installation mode: Base expansion screw fixation
Circuit structure: Applied in low explosion-proof or non-explosion-proof occasions
Calibration of analyzer: It is suggested that three or four standard gases and high purity nitrogen should be prepared for each calibration of zero and range points once a year.
System size: D*W*H=600mm*600mm*1750mm
Housing dimensions: D*W*H=2000mm*2000mm*2500mm
Packing box: Wooden box packing
System weight: About 100 Kg
