Measure range: 1~40kPa O2
Sensor: 3D Ion flow oxygen sensor
Accuracy: ±1% FS
Repeatability: ±0.5% FS
Stability: ±0.5% FS/7d
Response time: T90<15s
Display resolution: 0.01%
Measurement mode: portable
Calibration cycle: one year (recommended)
Power supply: 220VAC±,50/60Hz
Analyzer power consumption: <15VA
Standby time: more than 3.5 hours during normal test
Sensor life: more than 36 months (normal use)
Instrument life: more than 60 months (normal use)
Weight: 3kg±0.5kg (slightly different depending on configuration)
Sampling gas temperature: 0~50°C
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Sample flow rate: 400~600ml/min
Inlet: Standard 1/4-Φ6 Tetrafluoro Tube Joints (Replaceable)
Communication: RS485/RS232
Switch output: Alarm output:1 set; Relay contact point capacity:24V DC,0.2A
Analog output: 1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/ 1-5V,(You can set the mode freely). The load:less than 500 Ω
