Measure range: 10.00%~98.00%/ 99.99% O2
Sensor: 3D Ion flow oxygen sensor
Accuracy: ±1%FS
Repeatability: ±0.5%FS
Stability: ±0.5%/7d
Response time: T90<20s(after full preheating)
Circuit structure: applied to non-hazardous situations.
Weight of analyzer: net weight 2.15kg,about 3.05kg after packaging
Power supply: 85~264VAC,50/60Hz
Analyzer power consumption: <20VA
Communication: RS485(standard)/RS232(optional)
Relay contact point capacity: 24VDC,0.2A
Analog output: 1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/1-5V (You can set the mode freely).
Environment temperature: -10~55°C Environment Humidity:<85%RH
Sample gas pressure: atmospheric conditions±10%(Gas outletshould be atmospheric conditions)
Sensor life: more than 10 years (normal use)
Instrument life: more than 10 years (normal use)
Instrument size: L×W×D=188.5mm×98.5mm×207.5mm
Installation: Disk-mounted
Mounting hole size: L×W=170mm×90mm
