Measure range: 10.00%~97.00%/ 99.999% O2
Sensor: 3D Ion flow oxygen sensor
Accuracy: ±1%FS
Repeatability: ±0.5%FS
Stability: ±0.5%/7d
Response time: T90<20s
Circuit structure: applied to non hazardous situations.
Data storage: SD Card (Standard)/U Disk (Optional)
Power supply: 85~264VAC,50/60Hz
Analyzer power consumption: <35VA
Communication: RS485(standard)/RS232(optional)
Switch output: 6 sets; Relay contact point capacity:24V DC,0.2A
Analog output: 1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/ 1-5V,(You can set the mode freely). The load:less than 500 Ω
External input: Five groups
Environment Control signal 9~28VDC
temperature: -10~45°C Environment Humidity:<90%RH
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Instrument size: L×W×H=483mm×300mm×177mm
