Scope of measurement: 0.01%~10% H2(customizable range)
Accuracy: 0.3%
Repeatability: 0.2%
Stability: 0.2%/7d
Response time: T90<30s
Linearity: 0.2%
Concentrations of CO and H2S: 0
Background gases: N2,CO2,He,Ar,alkanes,olefins and alkynes. Other inert gases,excluding CO and H2S
Calibration background gas: N2
Monitor: 240×128 LCD screen
Key: Four keys (touch keys)
Data memory: SD card (standard)/U disk (optional)
Power supply: 85~264VAC,50/60Hz
Power consumption of analyzer: Less than 30VA
Communication: RS485 (Standard Matching)/RS232 (Optional Matching)
Alarm: Alarm output:6 sets of switching signals. Relay Contact Capacity:24VDC,0.2A
Analog output: Group 1,4-20mA/0-20mA/0-1V/0-5V/0-10V /1-5V,analog output mode can be set. Load:less than 500Ω
External control: Quantity:5 groups. Control signal:9-28VDC
Sensor life: More than 2 years (normal use)
Analyzer life: More than 5 years (normal use)
Environmental temperature: -10~45°C. Environmental humidity:less than 80%RH
Sample flow rate: 0.1-10 SLPM (recommendation 1.0 slpm)
Sample pressure: Atmospheric pressure ±10% (outlet should be atmospheric pressure)
Inlet and outlet: 1/4NPT (Standard 6.5 Stainless Steel Joint)
